UPOE-1600G Planet Инжектор 16-Port Gigabit 60W Ultra PoE Managed Injector Hub (600W)

UPOE-1600G Planet Инжектор 16-Port Gigabit 60W Ultra PoE Managed Injector Hub (600W)
81358.00 ₽
Производитель : Planet
Количество портов : 16

PLANET Ultra PoE Managed Injector Hub series, a cost-effective and quick Ultra PoE solution, is designed to perfectly upgrade an existing network infrastructure to Ultra Power over Ethernet network system without replacing the existing Ethernet Switch.

Ready to Deploy Next Generation Power over Ethernet

The UPOE-1600G is a high-density, rack-mountable managed Ultra PoE injector hub featuring PLANET intelligent PoE functions through web user interface for remote management. It provides 16 10/100/1000BASE-T Ethernet ports featuring Ultra PoE injector with a total PoE budget of 600 watts. Each PoE port can deliver up to 60-watt power over Cat.5/5e/6 Ethernet UTP cables which allow data and power to transmit simultaneously to a remote 60W and 802.3at/af powered device (PD). The UPOE-1600G enables centralization of the power supply and optimizes the installation and power management of remote network devices, and provides a quick, safe and cost-effective Power over Ethernet network solution for small businesses and enterprises.

Quick and Easy PoE Network Deployment

The UPOE-1600G is installed between a regular Ethernet Switch and the PDs. There are totally 32 RJ45 STP ports on the front panel of the UPOE-1600G, of which the16 ports are on the lower stack functioned as "Data input" while the other 16 ports are on the upper stack functioned as "PoE (Data and Power) output". Both power and data are transferred simultaneously over the UTP cables to PDs without affecting the existing network performance and functions.



  • Complies with the IEEE 802.3, IEEE 802.3u and IEEE 802.3ab Ethernet standards
  • 32-port RJ45

- 16-port 10/100/1000Mbps “Data input

- 16-port 10/100/1000Mbps “Data + Power output

  • One 10/100/1000BASE-T management port

Power over Ethernet

  • Ultra Power over Ethernet end-span/mid-span PSE
  • Up to 60 watts of power on 4-pair UTP
  • Backward compatible with IEEE 802.3at/af PD device
  • 52V DC, 60-watt PoE power output at maximum on each port
  • 600-watt PoE budget
  • Auto-detection of IEEE 802.3at/af PoE equipment and device to avoid possible damage by incorrect installation
  • Circuit protection prevents power interference between ports
  • Remote power feeding up to 100m

PoE Management

  • Per port PoE power schedule
  • PoE function enable/disable
  • Per port PoE function enable/disable
  • PoE port power feeding priority
  • PD classification detection
  • Over temperature protection
  • PD alive check
  • PoE schedule


  • Web interface for remote management
  • Supports Network Time Protocol (NTP)
  • Firmware upgrade through Web interface
  • PLANET Smart Discovery utility automatically finds PLANET devices on the network
  • SNMP trap for alarm notification of events
  • System log/remote syslog


  • 19-inch rack mountable; 1U height
  • Reset button for resetting to default setting and system reboot
  • LED indicators for PoE ready and PoE activity
  • LED indicators for power alert and fan alert
  • LED indicators for PoE power usage status (watts)
  • FCC Part 15 Class A, CE




■ “Data” Input Ports: 16 x RJ45

■ “Data + Power” Output Ports: 16 x RJ45

■ Management Port: 1 x RJ45; 10/100/1000BASE-T, auto-negotiation,


Data Rate




SYS PWR x 1 (Green)

PoE Failure x 1 ( Red )

Fan Failure x 2 ( Red )

Management port x 2:

1000 (Green), 10/100(Orange)

Per PoE Port:

Ultra 60W PoE-in-use x 1 (Green)

802.3at/af PoE-in-use x1 (Orange)

PoE Power Usage LED x4 (Green)

Power Requirements

100-240V AC, 50/60 Hz, 8A

Power Consumption

800 watts (max.)/2729BTU


Fan x 3

Dimensions (W x D x H)

440 x 300 x 44.5 mm, 1U height





Power over Ethernet

PoE Standard

IEEE 802.3af Power over Ethernet
IEEE 802.3at Power over Ethernet Plus
4-pair Ultra PoE

PoE Power Supply Type

End-span/Mid-span/UPoE(Ultra PoE)

Power Pin Assignment

Pair 1 end-span: 1/2(-), 3/6(+)
Pair 2 mid-span: 4/5(+), 7/8(-)
UPoE: 1/2(-), 3/6(+),4/5(+), 7/8(-)

PoE Power Output

DC 52V/60-watt PoE via 4-pair
DC 52V/30-watt PoE via 2-pair

PoE Power Budget

600 watts/2047BTU

Number of 60W PDs can be powered


Number of 802.3af PDs (Class 0, 1, 2, 3) can be powered


Number of 802.3at PDs (Class 1, 2, 3) can be powered


Number of 802.3at PDs (Class 0, 4) can be powered



Management Interface

Web, PLANET Smart Discovery Lite

PoE Management

Power limit by consumption and allocation
PoE admin mode
Per port power schedule
Per port power enable/disable
Power feeding priority
Over temperature protection
Current per port usage and status
Total power consumption
PD alive check
Scheduled power recycling

Management Feature

Setup of system/management functions
Web firmware upgrade
SNMP trap for alarm notification of events

Standards Conformance

Regulatory Compliance

FCC Part 15 Class A, CE

Standards Compliance

IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
IEEE 802.3at Power over Ethernet Plus
IEEE 802.3af Power over Ethernet
RFC 768: UDP
RFC 791: IP
RFC 2068 https
RFC 1157: SNMP v1
RFC 1902: SNMP v2c
RFC 5424: Syslog

Network Cable

10BASE-T: 4-pair UTP Cat5 up to 100m (328ft)
100BASE-TX: 4-pair UTP Cat5 up to 100m (328ft)
1000BASE-T: 4-pair UTP Cat5e/6 up to 100m (328ft)
EIA/TIA- 568 100-ohm STP (100m)



Temperature: 0 ~ 50 degrees C
Relative Humidity: 5 ~ 90% (non-condensing)


Temperature: -10 ~ 70 degrees C
Relative Humidity: 5 ~ 90% (non-condensing)
